Circuit breaker 6kA 10A 4P curve C Elmark

EL3070
1646
Availability: 1 pezzi
  • Make An Offer

Circuit breaker 6kA 10A 4P curve C Elmark



Technical features

  • Rated Operating Voltage: 230/400V; 50/60Hz
  • Rated current: 1-63A
  • Breaking capacity: 6000 А - Poles: 4
  • Trip curve: C
  • Curve С: The overcurrent release trips between 5 and 10 In
  • Used to protect main power cables and conventional utilities
  • Electrical wear resistance (number of cycles): ≥8000
  • Mechanical wear resistance (number of cycles): ≥50000
  • Limitation class: 3
  • IP code: IP> 20
  • Ambient temperature: -5 to + 65 ° С ± 2 ° С
  • Mounting: vertically on a rail
  • DIN Standard: EN60898-1
  • Model: C64N/10A
  • Rated Voltage: 400V
  • Rated Current: 10A
  • Breaking capacity: 6kA
  • Number of poles: 4
  • Shutdown curve: C
  • Overall dimension (mm): L:72/W:72/H:81
  • Brand:  ELMARK
  • EAN code: 3800131126917
  • Supplier code: 41410N
Brand
Elmark
Breaking power
6kA
Current
10A
Nominal tension
480V
Number of poles
4
Packaging
Loose
Supplier code
41410N
Find similar

PDF-1 (1.Technical_Specification-_MINIATURE_CIRCUIT_BREAKERS__MCB__C60N.pdf, 809 Kb) [Download]

PDF-2 (2.Declaration_of_conformity-_MINIATURE_CIRCUIT_BREAKERS__MCB__C60N.pdf, 518 Kb) [Download]

PDF-3 (Instruction_МСВ.pdf, 1,703 Kb) [Download]

PDF-4 (Intertek_Certificate_MCB.pdf, 309 Kb) [Download]

PDF-5 (ROHS_60N.pdf, 3,104 Kb) [Download]

PDF-6 (Technical_Specification-_MINIATURE_CIRCUIT_BREAKERS__MCB__C60N_OLD.pdf, 833 Kb) [Download]

PDF-7 (Test_reports_MCB.pdf, 4,475 Kb) [Download]
