Circuit breaker 6kA 4A 4P curve C Elmark
EL3088
MCB 6kA 4A 4P curve C Elmark
Technical characteristics
- Rated operating voltage: 230 / 400V; 50 / 60Hz
- Rated current: 1-63 A
- Breaking capacity: 6000 A
- Pole:4
- Intervention curve: C
- Curve C: The maximum current release interrupts between 5 and 10 In
- Used to protect main power cables and conventional utilities
- Electrical wear resistance (number of cycles): ≥8000
- Mechanical resistance to wear (number of cycles): ≥50000
- Restriction class: 3
- IP code: IP20
- Ambient temperature: from -5 a + 65 ° С ± 2 ° С
- Mounting : vertically on a DIN rail
- Standard: EN60898-1
- Template: C60N
- Nominal voltage: 400 V
- Rated current: 4 A
- Breaking capacity: 6 kA
- Number of poles: 4
- Overall size (mm): L: 72 / W: 72 / H: 81
- Brand: ELMARK
- EAN code: 3800131126894
- Vendor code: 41404N
Brand
Elmark
Breaking power
6kA
Current
4A
Nominal tension
480V
Number of poles
4
Packaging
Loose
Supplier code
41404N
